Vehicle engine driven unit for van
T-VAN
Roof mount condenser
Condenser
W : 1,230 / L : 1,130 / H : 280(mm)
Weight : 32kg
Evaporator
W : 864 / L : 576 / H : 159(mm)
Weight : 32.3kg
T-VAN refrigerating capacity (30ºC / 2400RPM)
Controller
: Main automatic temperature controller (Relay box separation type)
Automatic recovery during compressor input error,
built-in heat-resisting case CPU,
Consistent vehicle battery monitoring function
Option
: Temperature recording instrument
Compressor
: QP15 or TM15 (Displacement : 146cc / 6 Cylinders)
Applicable for van
Outside temperature : 30℃ / 40℃
0℃ 20m³/13m³
-20℃ 15m³/11m³
